Videx 3123 Installation Instructions

66251340-EN - V 2.0 - 24/07/15
3
3000 Series
Art.3171B - 3172 - 3176 - Installation instructions
PROGRAMMING
Programming is made by setting the internal 8 way dip-switch
to the positions shown on decimal/binary conversion table
(pag. 7) of this manual and the conguration of the number
of rings (3 or 6).
For the Art.3176 it is necessary to set the internal 3 way dip-
switch, to set the duration of the privacy mode, shown on the
table below.
SET THE NUMBER OF RINGS
The standard setting is 6 rings.
To change the rings setting make as follow:
• Switch o the intercom disconnecting the “L” wire;
• Short-circuit terminals “–” and “LB”;
• Switch on the intercom connecting again “L”;
• Remove the short-circuit as soon as the intercom emit the conrmation beeps:
» if are emitted two beep, rings are set to 6;
» if is emitted one beep, rings are set to 3;
• Repeat again the operation if the number of rings set is not the required one.
SEÑALES DE LA BORNES
L
“BUS” bus connection.
–
LB Local bell input (ground signal).
AL Alarm input (ground signal).
The alarm generated by this input will
be sent to the concierge (if present) and
will be intercepted by the Art.512DR if
present and correctly congured.
SW (only VX3171, VX3172)
Service push button terminals
SW (only VX3171, VX3172)
LD– (only VX3176)
Terminals for “Door Open” LED supply
LD+ (only VX3176)
TECHNICAL SPECIFICATIONS
Addressing range: from 1 to 180 (BIN code)
Working voltage: BUS line Voltage
Stand-by absorption: about 0.6 mA
Phone max. absorption: about 80mA
Working temperature: -10 +50 C°
DIP SWITCH S1
TIME
1 2 3
OFF OFF OFF Unlimited
ON OFF OFF 15 min
OFF ON OFF 30 min
ON ON OFF 1 hour
OFF OFF ON 2 hours
ON OFF ON 4 hours
OFF ON ON 8 hours
ON ON ON 16 hours
Art.3171B - 3172 - 3176 Digital intercoms
CUSTOMER SUPPORT
All Countries:
VIDEX ELECTRONICS S.P.A.
www.videx.it - technical@videx.it
Tel: +39 0734-631669
Fax: +39 0734-632475
UK Customers:
VIDEX SECURITY LTD
www.videx-security.com
Tech Line: 0191 224 3174
Fax: 0191 224 1559
The product is CE marked demonstrating its conformity and is for distribu-
tion within all member states of the EU with no restrictions. This product
follows the provisions of the European Directives 2004/108/ECC (EMC);
2006/95/ECC (LVD) and 93/68/ECC (CE marking).
Main UK o ce:
VIDEX SECURITY LTD
1 Osprey Trinity Park
Trinity Way
LONDON E4 8TD
Phone: (+44) 0870 300 1240
Fax: (+44) 020 8523 5825
www.videx-security.com
marketing@videx-security.com
Northern UK o ce:
VIDEX SECURITY LTD
Unit 4-7
Chillingham Industrial Estate
Chapman Street
NEWCASTLE UPON TYNE - NE6 2XX
Tech Line: (+44) 0191 224 3174
Phone: (+44) 0870 300 1240
Fax: (+44) 0191 224 1559
Greece o ce:
VIDEX HELLAS Electronics
48 Filolaou Str.
11633 ATHENS
Phone: (+30) 210 7521028
(+30) 210 7521998
Fax: (+30) 210 7560712
www.videx.gr
videx@videx.gr
Danish o ce:
VIDEX DANMARK
Hammershusgade 15
DK-2100 COPENHAGEN
Phone: (+45) 39 29 80 00
Fax: (+45) 39 27 77 75
www.videx.dk
videx@videx.dk
Benelux o ce:
VIDEX BENELUX
E3 Iaan, 93
B-9800 DEINZE
Phone: (+32) 9 380 40 20
Fax: (+32) 9 380 40 25
www.videxbenelux.be
info@videxbenelux.be
VIDEX ELECTRONICS S.P.A.
Via del Lavoro, 1 - 63846 Monte Giberto (FM) Italy
Tel (+39) 0734 631669 - Fax (+39) 0734 632475
www.videx.it - info@videx.it
