Viessmann VITOTRONIC 100 User Manual

30
The DHW circulation pump transports the DHW
through a loop line between the DHW cylinder and the
draw-off points (e.g. hot tap). This ensures that hot
water is rapidly available to you when you open the
tap.
You can set individual time phases for DHW circulation
pump operation.
Factory setting: "Automatic"
In automatic mode, the DHW circulation pump oper-
ates in parallel to the "Time program" for DHW heat-
ing.
Tap the following on-screen buttons:
1. If required, for the home screen
2. for the main menu
3. "DHW" for DHW heating settings
4. "Time program, DHW circulation"
5. If required, "Heating circuit 1"
or
"Heating circuit 2"
or
"Heating circuit 3"
6. "Individual"
7. to confirm
To see how to set a time program, see page 20.
Switching off DHW heating
Deactivate DHW heating.
Tap the following on-screen buttons:
1. If required, for the home screen
2. for the main menu
3. "DHW" for DHW heating settings
4. "DHW set temperature"
5. for 10 °C
6. to confirm
Vitotronic 300: DHW heating
Setting the "Time program" for DHW heating (cont.)
5863758

Viessmann VITOTRONIC 100 Specifications

General

Display	LCD
Programming	Programmable
Temperature Control	Yes
Compatibility	Viessmann heating systems
Type	Electronic control unit
Application	Heating systems
Operating Voltage	230 V AC
Protection Class	IP20
Weight	0.5 kg
Control Functions	Heating circuit control
Control Type	Weather-compensated control
