For square plug and play spas, the RCD
cord can be accessed through the notched
knockout as shown to the right. You may have
to remove the equipment access panel and
route the cord through the opening.
For the round Viking 1P or 2P spas, you will
need to remove the panel with the cord cutout
in the lower left hand section of the panel to
access the RCD cord. Attach the panel back
onto the spa with the cord routed through the
notch section of the panel.
PlUG & PLAY CORD
LOCATION
Notched where cord
is located on square
plug and play spas
06
