Section 5: Mount Installation
Keep the foam underneath the monitor before attaching the stand to a mount
or accessory.
1. Open the package, take out the product with foam still attached, and gently
place it on a desktop or table. Remove the extra parts and the foam covering the
back of the monitor. If the monitor is already attached to the stand, remove the
stand and unfasten the two NO.1 screws from it.
Monitor
Stand Base
Foam
Stand Stem
2. Fit the VESA adapter into the opening on the back of monitor, then use the NO.1
screws to fasten it to the monitor.
NO.1 Screws
6mm x 2
VESA Adapter
(75 x 75mm)
3. Follow the directions received with your mount, stand, or accessory and install
the monitor on the wall or xture as desired.
Mount
(Not included)
