Viotek GNV32DB User Manual

10
Section 8: OSD
The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings
and appears on screen after turning on the monitor and pressing the M button.
When using the monitor for the rst time, settings will automatically adjust to
optimal settings according to your computer’s conguration.
1. Press any one of the buttons (M, , , E, ) to activate the navigation window.
eco
2. Press M ( ) to enter the OSD menu.
DP
Resolution：1920x1080@60Hz
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
DP
HDMI 1 (2.0)
HDMI 2 (1.4)
HDMI 3 (1.4)
Window1：
InputSource：DP
Resolution：1920x1080@60Hz
Window2:
InputSource：
Resolution：
DP
Resolution：2560x1440@60Hz
Input Source
Brightness/Contrast
Color Setting
Picture Quality Setting
Display
Audio
Multi-Window
OSD
Other
DP
HDMI 1 (2.0)
HDMI 2 (1.4)
HDMI 3 (1.4)
Window1：
InputSource：HDMI2
Resolution：2560 x1440@60Hz
Window2:
InputSource：
Resolution：
3. Press ( ) or (
eco
) to browse functions.
• Highlight the desired function, then press M ( ) to enter the sub-menu.
• Press ( ) or (
eco
) to browse sub-menus, then press M ( ) to highlight the
desired function.
• Press ( ) or (
eco
) to highlight an option, then press M ( ) to conrm the
settings and exit the current screen.
4. Press E ( ) to exit the current screen.

Viotek GNV32DB Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Wall Mount	75mm x 75mm
OS Compatibility	windows, mac, linux
Screen Size	32 inches
Panel Type	va
Aspect Ratio	21:9
Resolution	2560 x 1440
Refresh Rate	144hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	4 milliseconds
Brightness	250 candela per square meter
Contrast Ratio	1, 000, 000:1
Display Port Inputs	1
DVI	1
Depth with Stand	8.91 inches
Height with Stand	19.9 inches
Width with Stand	28.05 inches
Net Weight without Stand	15.58 pounds
