Viotek GNV32DB User Manual

9
Section 6: Basic Operation
1. Insert one end of the DisplayPort (DP) cable into your PC’s graphics card. An
HDMI cable (not included) may also be used.
2. Connect the other end of the cable to the corresponding connector on your
monitor.
Audio Out HDMI Ports
Power Connector
DP Port HDMI2.0 HDMI1.4
3. Connect the power cable to your monitor then connect the other end to your
power source. It is recommended that you use a surge protector with adequate
voltage if a wall outlet cannot be reached directly.
4. Locate the power button on the monitor and press it to turn the monitor on.
AMD FreeSync
This feature is off by default. To activate, you must have hardware with FreeSync
capability, a DP or HDMI cable, and the latest graphic drivers. After connecting your
computer and monitor with a DP or HDMI cable, you may receive a prompt to enable
the feature on your computer. If you do not, you may need to enable the function in
your graphics card menu. See your graphics card manufacturer’s documentation for
instructions.
Section 7: Indicator Light
Indicator Light
Solid blue light indicates power is on and the monitor is operating normally. Flashing
blue light indicates no video source, no horizontal or vertical signal has been
detected or voltage is low. Please ensure your computer is on and all video cables
are fully inserted and/or connected.

Viotek GNV32DB Specifications

General

Color	black
Screen Type	led
Tiltable	yes
Wall Mount	75mm x 75mm
OS Compatibility	windows, mac, linux
Screen Size	32 inches
Panel Type	va
Aspect Ratio	21:9
Resolution	2560 x 1440
Refresh Rate	144hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	4 milliseconds
Brightness	250 candela per square meter
Contrast Ratio	1, 000, 000:1
Display Port Inputs	1
DVI	1
Depth with Stand	8.91 inches
Height with Stand	19.9 inches
Width with Stand	28.05 inches
Net Weight without Stand	15.58 pounds
