Viotek GNV34DBE2 User Manual

6
Section 3: Product Overview
3.1 – Monitor Buttons
7
Power Connector: Insert the power cable to supply power to the monitor.
8
Audio Output: Insert the audio cable for output of audio signals.
9
DP Connectors: Insert one end of the DisplayPort (DP) cable into the
computer’s DP output and connect the other end to the monitor’s DP port.
10
HDMI Connectors: Insert one end of the HDMI cable into the computer’s
HDMI output and connect the other end to the monitor’s HDMI port.
7 9 10
8
2 3 4 5 61
1
M Menu Button
: Press to display the OSD menu or enter sub-menus.
2
Down Button
: Press to move down in the menus.
3
Up Button
: Press to move up in the menus.
4
E Exit Button
: Press to exit.
5
Power Button
: Press to turn the monitor on/off.
6
LED Indicator: Changes colors to indicate status. Refer to Section 7.
The E button can also be used to switch between “Limit” and “Full” color gamuts when
a compatible graphics card and either HDMI or DP cables are used.
3.2 – Monitor Ports

Viotek GNV34DBE2 Specifications

General

Color	black
Screen Type	lcd
Tiltable	yes
Wall Mount	75mm x 50mm
Webcam	no
OS Compatibility	linux, mac, windows, not applicable
Screen Size	34 inches
Panel Type	va
Aspect Ratio	21:9
Resolution	3440 x 1440
Refresh Rate	144hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	4 milliseconds
Brightness	350 candela per square meter
Contrast Ratio	1, 000, 000:1
Synchronization	freesync (amd adaptive sync)
HDR	no
Built-In Speakers	no
Interface Connectors	2 x displayport 1.4
HDMI Ports	2
Display Port Inputs	2
Depth with Stand	8.88 inches
Height with Stand	17.88 inches
Width with Stand	31.83 inches
Net Weight without Stand	15.47 pounds
