Viotek GNV34DBE2 User Manual

7
Section 4: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package and take out the monitor with foam still attached. Gently place
it top-down on a desktop or table.
2. Take out the stem, cable clip and base. Use the included screwdriver and one
screw to fasten base to the stem.
Screw x 1
Stand Stem
Headphone Clip
Base
3. Remove the foam covering the bottom of the monitor, then remove the adapter
from the back of monitor. Use two NO. 1 screws to fasten adapter onto the stem.
Adapter
Screws x 2
4. With the stand fully assembled, reattach it onto the back of monitor. Then remove
the remaining foam on monitor and stand it up on a at, level desktop or table.
Press the button to remove the monitor from the bracket if mounting.
Button
Make sure the monitor is laid on a at surface before removing the stand.

Viotek GNV34DBE2 Specifications

General

Color	black
Screen Type	lcd
Tiltable	yes
Wall Mount	75mm x 50mm
Webcam	no
OS Compatibility	linux, mac, windows, not applicable
Screen Size	34 inches
Panel Type	va
Aspect Ratio	21:9
Resolution	3440 x 1440
Refresh Rate	144hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	4 milliseconds
Brightness	350 candela per square meter
Contrast Ratio	1, 000, 000:1
Synchronization	freesync (amd adaptive sync)
HDR	no
Built-In Speakers	no
Interface Connectors	2 x displayport 1.4
HDMI Ports	2
Display Port Inputs	2
Depth with Stand	8.88 inches
Height with Stand	17.88 inches
Width with Stand	31.83 inches
Net Weight without Stand	15.47 pounds
