16
Light indicator is on or flashing, but there is no image displayed on screen
• Check if the monitor is receiving power.
• Check if the graphics card is installed properly.
• Make sure the HDMI cable is securely connected to the monitor.
• Make sure the pins within the cable’s connectors are not damaged.
Color shortage (red, green, or blue)
• Make sure the pins within the cable’s connectors are not damaged.
Image position is not centered/the size is not right
• Please adjust Clock or Auto settings.
Color difference (colors are not optimized)
• Adjust RGB colors or reset color temperature.
Section 12: Specifications
Item Detail
Model Number NB32CW/NB32CB
Screen Size 31.5’’
Curvature 1800R
Viewing Angle 178° (H)/178° (V)
Aspect Ratio 16:9
Resolution 1920x1080p
Backlight E-LED
LED Indicator Power on: Blue (LED); Power saving : Blue Flicker (LED)
Typical Brightness 250 cd/m
2
Default Color Temp. 6500
Color Gamut 92% sRGB; 68% NTSC
Contrast Ratio 3,000:1 (Static)
Dot Pitch 0.3637x0.1212mm
Response Time GTG 8Ms
Refresh Rate 60-75Hz (75 Max.)
Speaker NA
Ports VGA x 1, HDMI x 1, Audio x 1 (Output)
Power AC100-240V, 50/60Hz 1.5A
Power Consumption Typical: 36W, Max: 50W; Standby ≤ 0.5W
OSD Language
English, Español, Русский, Français, 한국, Português,
Deutsch, Türkçe, 简体中文, Polski, Italiano, Nederlands
Usage Temp. 32°F~95°F (Operating), -4°F~140°F (Storage), 10-90%
RH (Non-Condensation)
Tilt Angle Forward 5°; Backward 15°
VESA Compatibility 75x75mm
Dimension (With Stand) 28.3x9.8x19.5” (718.26x248.08x496.83mm)
Weight 17.6lbs (Net) / 22lbs (Gross)
