Vizio D55-D2 User Manual

1
Installing the TV on a Wall
To mount your TV on a wall, you will need a ZDOOPRXQW&RQVXOWWKHLQIRUPDWLRQEHORZWRȴQGWKH
appropriate mount for your TV model:
Be sure the mount you choose is capable of supporting the weight of the TV. After you have
determined that you have the correct mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. 3ODFHWKH79IDFHGRZQRQDFOHDQȵDWVWDEOHVXUIDFH%HVXUHWKHVXUIDFHLVFOHDURIGHEULV
that can scratch or damage the TV.
3. Remove the stands by loosening and removing
the screws.
4. Attach your TV and wall mount to the wall, carefully following the instructions that came with
your mount. Use only with a UL-listed wall mount bracket rated for the weight/load of this TV.
For some wall mounts, you may want to use cables
with right-angle connectors. This allows the TV to rest
closer to the wall.
WALL-MOUNT SCREW LOCATIONS
D43-D2 D55-D2 D65-D2
Screw Size: M6 M6 M6
Hole Pattern: 200mm (V) x 200mm (H) 200mm (V) x 200mm (H) 400mm (V) x 400mm (H)
Weight w/o
Stand:
17.64 lbs 30.42 lbs 49.60 lbs
Installing a TV on a wall requires lifting. To prevent
LQMXU\RUGDPDJHWRWKH79DVNVRPHRQHWRKHOS\RX
9

Vizio D55-D2 Specifications

General

Display diagonal	55 \
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Full-Array
Contrast ratio (dynamic)	5000000:1
Display number of colors	16.78 million colors
Ambient light sensor	Yes
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
3D	No
RMS rated power	30 W
Number of speakers	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Remote control type	XRT122
Sustainability certificates	ENERGY STAR
Power consumption (standby)	1 W
Power consumption (typical)	40.32 W
Panel mounting interface	200 x 200 mm
Package depth	160.02 mm
Package width	1465.07 mm
Package height	829.06 mm
Package weight	19500 g

Weight and Dimensions

Depth (with stand)	249.94 mm
Width (with stand)	1240.03 mm
Height (with stand)	782.57 mm
Weight (with stand)	14200 g
Depth (without stand)	68.07 mm
Height (without stand)	722.63 mm
Weight (without stand)	13800 g
