Volkswagen VAS6131/19 User Manual

• When using the load handling device,
ensure that the load being lifted is
safely secured by the pins provided
(item 2). To do so, extend the pins by
hand until they are in full contact with
the load.
• All required screw connections on the
vehicle have to be unscrewed before
lowering the battery.
• Pushing the load while it is raised is
not permitted.
• Possible ne-tuning for positioning the
battery under the vehicle must be
carried out only with the VAS6131B
lifting table (item 4).
• The mountings may only be used and
moved together with the VAS6131B
table.
4 | Operation
• The VAS6131/19 mounting is a load
handling device for the installation and
removal of high-voltage motor vehicle
batteries.
• Four mountings have to be used for
removal.
• The maximum total permissible load
bearing capacity of one mounting is
300kg, and of four mountings
900kg.
• For use only in the congurations
dened in the repair guide for the
brands of the VW Group in
combination with the VAS6131B
liftingtable.
Applications and pulling directions other than those described in the repair guide are
not intended and therefore prohibited!
NOTICE
The maximum permissible movement speed is 2 km/h.
DANGER
• The top of the VAS6131B lifting table
has to be lowered before movement.
• The load must be protected against
unwanted impacts (e.g. tension belt).
• Tighten the M10x20 hexagon bolts
(item 3) to 25Nm.
• Using parts of this load handling
device individually is not permitted.
