Volvo Penta D5A User Manual

General
Type Designation D5A T RC
No. of cylinders 4
Displacement
4,76 liters (290 in
3
)
Dry weight
(1)
, engine without generator and frame, approx.
510 kg (1124 lbs)
Valve clearance, setting values (cold engine)
Inlet 0,30 mm (0,0118’’)
Exhaust 0,50 mm (0,0197’’)
1) excl. engine oil and coolant
Exhaust temperatures
(1)
73 kW @ 1500 rpm 74 kW @ 1800 rpm
at 25% of ISO Standard Power 210°C (410°F) 205°C (401°F)
at 50% of ISO Standard Power 300°C (572°F) 280°C (536°F)
at 75% of ISO Standard Power 385°C (725°F) 340°C (644°F)
at 100% of ISO Standard Power 455°C (851°F) 385°C (725°F)
at 110% of ISO Standard Power 480°C (896°F) 400°C (752°F)
1) Approximated values, temperatures varies with ambient temperature and back pressure in the exhaust line.
General
Type Designation D5A T KC (1-circuit)
No. of cylinders 4
Displacement
4,76 liters (290 in
3
)
Dry weight
(1)
, engine without generator and frame, approx.
510 kg (1124 lbs)
Valve clearance, setting values (cold engine)
Inlet 0,30 mm (0,0118’’)
Exhaust 0,50 mm (0,0197’’)
1) excl. engine oil and coolant
Exhaust temperatures
(1)
77 kW @ 1500 rpm 81 kW @ 1800 rpm
at 25% of ISO Standard Power 210°C (410°F) 205°C (401°F)
at 50% of ISO Standard Power 300°C (572°F) 280°C (536°F)
at 75% of ISO Standard Power 385°C (725°F) 340°C (644°F)
at 100% of ISO Standard Power 455°C (851°F) 385°C (725°F)
at 110% of ISO Standard Power 480°C (896°F) 400°C (752°F)
1) Approximated values, temperatures varies with ambient temperature and back pressure in the exhaust line.
Technical Data
47713337 03-2021 © AB VOLVO PENTA 97
