Technical Data
Type designation IPS 1050 IPS 1200
Crankshaft power @ 2300 rpm.
(1)
588 kW (800 hk) 671 kW (900 hk)
Max torque 2934 Nm (2164 lbf.ft) /
800–1900 rpm
3300 Nm (2434 lbf.ft) /
900–1600 rpm
After market designation D13B-C MP D13B-G MP
No. of cylinders in-line 6 in-line 6
Bore 131 mm (5.16”) 131 mm (5.16”)
Stroke 158 mm (6.22”) 158 mm (6.22”)
Displacement
12.78 dm
3
(779.7 in
3
) 12.78 dm
3
(779.7 in
3
)
Engine, dry weight 1560 kg (3439 lbs) 1560 kg (3439 lbs)
Compression ratio 16.7:1 16.7:1
Low idle, r/min. 600 (±10)
(2)
600 (+10)
(3)
1) According to ISO 8665
2) At delivery, the idle speed is adjusted to 600 r/min. If needed, the speed can be adjusted within the range 600–650 r/min.
3) At delivery, the idle speed is adjusted to 600 r/min. If needed, the speed can be adjusted within the range 600–650 r/min.
47702096 05-2011 121
