1. Check that the auxiliary battery has the same
voltage as the engine system voltage.
2. Connect the red positive cable to the plus (+) ter-
minal on the discharged battery and then to the
plus terminal on the auxiliary battery.
3. Connect the black start cable to the negative (–)
terminal on the auxiliary battery and to a place a
little distance away from the discharged battery
(e.g. the starter motor's negative terminal).
DANGER!
The black jumper cable (–) must never come in
contact with the positive connection on the starter
motor. Risk of arcing and explosion.
4. Start the engine and let it run at fast idle for
approximately 10 minutes to charge the batteries.
Make sure there is no extra equipment connected
to the electrical system.
In Case of Emergency
47701898 12-2010 105

Volvo Penta SX-A Specifications

General

Type	Sterndrive
Drive Unit	SX-A
Propeller Options	Aluminum, Stainless Steel
Trim System	Power Trim
Engine Compatibility	Volvo Penta Gasoline Engines
Standard Rotation	Right-hand rotation
Steering	Power steering
Steering Angle	28°
Trim Range	-4° to +12°
Maximum Engine Power	430 HP
Gear Ratio	1.60:1
