Inlet and Exhaust System
Tank Small Medium Large X Large
Usable volume 17.4 liters
(4.54 US gal)
38.6 liters
(10.2 US gal)
68 liters
(17.96 US gal)
164.2 liters
(43.38 US gal)
Electrical System
System voltage 24 V
Batteries 2 pcs. series connected
Battery voltage 12 V
Max. Battery capacity 2 x 225 Ah
Alternator
ambient temperature 20 °C
Engine speed 600 rpm 700 rpm 950 rpm 1250 rpm
Alternator, 110 A 80 A 95 A 110 A 115 A
Alternator, 130 A 78 A 95 A 113 A 130 A
ambient temperature 100 °C
Engine speed 600 rpm 700 rpm 950 rpm 1250 rpm
Alternator, 110 A 65 A 78 A 88 A 93 A
Alternator, 130 A 65 A 80 A 92 A 102 A
Starter motor, output 5.5 kW (7.4 hp)
Battery electrolyte specific gravity at +25 °C:
Fully charged battery
1.28 g/cm
3
(1.24 g/cm
3
)*
Battery recharged at
1.20 g/cm
3
(1.20 g/cm
3
)*
Note! * Applies to batteries with tropical acid.
Technical Data
88
47711083 09-2018 © AB VOLVO PENTA
