Volvo D9 User Manual

Communication
J1939 Backbone 1 (BB1) - EMS
NOTICE! All unused signals must be set to ‘Not available’.
All unused bits in the messages used must be set to 1.
Identifier PGN SPN Frame Name / Signal name Update
period
Tx = transmit
Rx = receive
0x18FECA00 DM1 - Active Diagnostic trouble codes
Description: The message contains the first active diagnostic
trouble code, but requires the multipacket transport TP. CM
when more than one active DTC exists.
Tx 1000ms
0x18FEE300 65251 EC1 - Engine configuration Tx 5000ms
or on request
188 Engine speed at idle P1
539 Engine percent torque at idle P1
528 Engine speed at P2
540 Engine percent torque at P2
529 Engine speed at P3
541 Engine percent torque at P3
530 Engine speed at P4
542 Engine percent torque at P4
531 Engine speed at P5
543 Engine percent torque at P5
532 Engine speed at high idle P6
544 Engine reference torque
533 Engine maximum momentary override speed P7
534 Engine maximum momentary override time limit
0x0CF00400 61444 EEC1 - Electronic engine controller 1 Tx 20ms
512 Drivers demand engine - percent torque
513 Actual engine - percent torque
190 Engine speed
1675 Engine starter mode
0x0CF00300 61443 EEC2 - Electronic engine controller 2 Tx 50ms
91 Accelerator pedal position 1
92 Engine percent load at current speed
0x18FEDF00 65247 EEC3 - Electronic engine controller 3 Tx 250ms
514 Nominal friction - percent torque
27 Engine exhaust gas recirculation 1 valve position
94 Engine fuel delivery pressure
100 Engine oil pressure
109
Engine coolant pressure
(1)
111 Engine coolant level
0x18FEEE00 65262 ET1 - Engine temperature 1 Tx 1000ms
110 Engine coolant temperature
175 Engine oil temperature 1
Communication, J1939 Backbone 1 (BB1) - EMS
47706587 05-2015 © AB VOLVO PENTA 23

Volvo D9 Specifications

General

Engine Type	Diesel
Cylinders	6
Displacement	9.4 liters
Torque	1050-1700 Nm depending on specific model
Configuration	Inline
Aspiration	Turbocharged
Cooling System	Liquid-cooled
