8 Operation and use
30 100_0202_op_0011.fm
Remote-controlled machinery – direction of movement
The direction of movement of the machine is self-contained from the position of the operator. If the
joystick of the remote control is pressed forward, the machine moves always forward.
8.3 Commissioning
8.3.1 Activate machine
1. Pull hood opener of rear protective hood until it is unlocked.
2. Completely open the rear protective hood with the hood opener.
3. Press the ON/OFF switch on the machine.
WARNING
Mixing up the direction of movement of the machine poses a danger of crushing for others
Operate the machine from behind and maintain a minimum safety distance of at least
2 meters.
Ensure that no other individuals are in the proximity area or working area of the
machine.
Operator behind the machine Operator in front of the machine
If the operator is located behind the machine and
presses both joysticks forward – the machine
moves forward away from the operator.
If the operator is located in front of the machine
and presses both joysticks forward – the machine
moves backward away from the operator.
DANGER
Fire hazard
Jumper cable sprays are highly flammable; they can ignite and cause severe burns.
Do not use jumper cable sprays.
Item Designation Item Designation
1 Control lamps 3 ON/OFF switch (red)
2 Display
