English
6
1. Assembly
Start
1. To extend the cart handle, push
the two cart buttons and pull
the handle out until it locks into
place.
2. Thread one end of the spray
hose to the outlet valve on the
sprayer.
3. Tighten the hose with an
adjustable wrench.
You will need:
• Adjustable wrench
IMPORTANT: Do not plug in the
power cord until assembly is
complete.
Note: It will be much easier to
attach the hose to the sprayer if
you uncoil it first.
5. One gallon setup -
Swing the 1-gallon pail bracket toward the front of
the sprayer. Hook the material container on the
pail bracket.
6. Five-gallon setup -
Swing the 1-gallon pail bracket toward the rear of
the sprayer until it is secured as shown. Hook the
5-gallon container onto the 5-gallon pail bracket as
shown.
1 2 3
4 5
