W 570 Flexio
21. Spare Parts
Spare Parts List Wall Extra I-Spray spray attachment (Fig. 23)
Pos. Designation Order No.
Wall Extra I-Spray spray attachment complete with 1300 ml
container
2361 746
1 Spray jet adjustment ring 2353 697
2 Union nut 2353 698
3 Air cap 2363 208
4 Air screen 2362 886
5 Nozzle 2328 908
6 Nozzle seal (2 pcs.) 2304 433
7 O-ring of spray attachment 2362 875
8 Ventilating hose, valve cover, diaphragm 2304 027
9 Suction tube 2328 922
10 Container seal 2328 919
11 Container with cover 1300 ml (only for Wall Extra I-Spray spray
attachment)
2305 155
Spare Parts List Standard spray attachment (Fig. 24)
Pos. Designation Order No.
Standard spray attachment complete with 800 ml container 2361 730
AUS 2361 731
1 Union nut 2362 873
2 Air cap 2362 877
AUS 2361 747
3 Nozzle 2362 878
4 Nozzle seal 0417 706
5 O-ring of spray attachment 2362 875
6 Ventilating hose, valve cover, diaphragm 2304 027
7 Suction tube 2362 876
8 Container seal 2323 039
9 Container with cover 800 ml 0413 909
Spare Parts List W 570 (Fig. 25)
Pos. Benennung Best. Nr.
1 Air lter cover (right + left) 2335 172
2 Air lter set (2 pcs.) 2333 123
3 Stirring rod 2304 419
4 Feed hopper (3 pcs.) 2304 028
Lubricating grease (no g.) 2315 539
