WAGNER W 570 FLEXIO User Manual

GB
35
W 570 Flexio
Problem Cause Remedy
Coating material
causes "paint tears"
•
Too much coating material
applied.
➞ Turn material volume
adjusting screw to the
left (-)
Too much fog of
coating material
(Overspray)
•
Distance to the object too large
•
Too much coating material
applied
•
Amount of air too high
➞ Reduce distance
➞ Turn material volume
adjusting screw to the
left (-)
➞ Decrease air quantity
(Level: Wood & Metal
)
Width of paint spray
cannot be adjusted
•
Adjustment ring is not connected
to the peg on the air cap
•
Air screen is clogged up
➞ Connect adjustment
ring and peg
➞ Disassemble and clean
Paint in the
ventilating hose
•
Diaphragm soiled
•
Diaphragm defective
➞ Clean the diaphragm
➞ Replace the diaphragm
Poor covering
capacity on the wall
•
Spray material is too cold
•
Highly absorbent surface or paint
with poor covering capacity
•
Distance too large
➞ The material you are
spraying should be at
room temperature
➞ Cross spray (Fig. 11)
➞ Closer to the object
24. Technical Data
Technical Data
Max. viscosity (Interior wall paint/Wall Extra
I-Spray spray attachment): 4000 mPas
Power source: 230 V
~
, 50 Hz / 240 V
~
, 50 Hz
Power consumption: 630 W / 660 W
Atomizing output: 100 W (min), 200 W (max)
Max. ow rate (Interior wall paint/Wall Extra
I-Spray spray attachment): 500 ml/min
Protection Class: I
Sound pressure level*: 74 dB (A); Uncertainty K = 4 dB
Sound pressure output*: 87 dB (A); Uncertainty K = 4 dB
Oscillation level*: < 2.5 m/s²; Uncertainty K = 1.5 m/s²
Weight: 1.9 kg
* Measured in accordance with EN 60745-1

WAGNER W 570 FLEXIO Specifications

General

Brand	WAGNER
Model	W 570 FLEXIO
Category	Paint Sprayer
Language	English
