GB
10
W 180P
Cleaning and Maintenance
The spray gun can only operate satisfactorily if it is cleaned and preserved after each
use.
Attention! Never immerse the spray gun in liquid when cleaning.
1 Empty out the remaining paint from the container.
2. Put proper thinner in the container and trigger the sprayer for approx. 2 seconds.
3. Pull the main plug out of the socket.
4. Disassemble the spray gun as shown in Illus. 9 (spare parts).
5. Thoroughly clean all soiled parts.
6. Reassemble the parts in reverse order.
7. Put a few drops of oil (e.g. sewing machine oil) in the intake and runback holes
(Illus. 7, arrow). Briefly switch on the spray gun.
Flexible Nozzle Extension (Illus. 4 + 8)
For spraying ceilings, resting objects or hard-to-reach areas e.g. radiators.
Spare Parts List W 180 P
Pos Name Order No.
1 Suction tube 0413 305
2 Paint container with cover 0413 909
3 Nozzle 0,8 mm 0046 903
4 Locking nut 0413 310
5 Valve 0209 042
6 Pump housing 0413 202
7 Piston spring 0033 028
8 Piston 0198 207
9 Nozzle spanner 0199 327
10 Viscosity measuring cup (small) 0209 058
Accessories W 180 P
Designation Order No.
Round spray nozzles for various spray materials:
Thick spray materials / nozzle size: 1,0 0046 906
Very thin spray materials / nozzle size: 0,5 0046 894
Paint container with cover 0413 909
Needle-jet nozzle 0209 045
Flexible nozzle extension with atomiser 0046 675
