Welch Allyn PanOptic 11820 User Manual

15
Lamp Replacement Instructions
Lamp Replacement Caution: Halogen lamps are pressurized to pro-
vide maximum efficiency and illumination. Mistreatment may
cause shattering. Protect lamp surface against abrasion and
scratches. Verify power is off when replacing lamp. Dispose of lamp
with care.
CAUTION: Lamps may be hot. Lamp should be
allowed to cool before removal. Use only Welch
Allyn model 03800 lamp with this product
ALIGN TAB
Use your fingernail or
a small prying instru-
ment to remove the
lamp from the oph-
thalmoscope head
base.
To insert the new
lamp, align tab on
lamp with notch in
the base of the oph-
thalmoscope had and
push inward until
firmly seated.
