08
PRE-DIVE INSPECTION
CONNECTING THE LP HOSE
To allow for proper operation of the inator it must be
connected to the LP port of the 1st stage of the regulator
using the LP hose supplied with the BC.
In order to connect the LP hose to the inator you should
gently pull at the sleeve of the LP hose’s nozzle (step 1),
and then put the nozzle onto the quick connector (step 2),
as presented in the pictures below:
Fig. 6. LP hose connection
STEP 02
Fig. 5. LP hose connection
STEP 01
DANGER
LP HOSE CONNECTION USING THE 1ST STAGE OF
THE REGULATOR MUST BE MADE TO THE LOW
PRESSURE (LP) PORT ONLY. CONNECTION TO THE
HP PORT MAY RESULT IN SERIOUS INJURIES AS
WELL AS DAMAGE TO THE EQUIPMENT.
WARNING
THE INFLATOR SUPPLY PRESSURE VALUE SHO-
ULD BE BETWEEN 6 AND 15 BAR. BEFORE CON-
NECTING THE INFLATOR TO THE LP HOSE, MAKE
SURE THAT THE PRESSURE FROM THE REGULA-
TOR IS WITHIN THIS RANGE.
26
