Xerox C410 Manual

Using the Keyboard
To enable keyboard navigation on the printer, plug a supported USB keyboard into the USB port and press the TTaabb
key to initiate the focus cursor.
NAVIGATING THE SCREEN USING THE KEYBOARD
Note:
• Xerox recommends a standard USB keyboard.
• Keyboard navigation is compatible with Voice Guidance.
• This option is available only in some printer models.
PPAARRTTSS OOFF TTHHEE KKEEYYBBOOAARRDD FFUUNNCCTTIIOONN
Tab Move the focus cursor to the next item on the screen.
Note: Use the TTaabb key as the primary method for navigating the screen
with a keyboard.
Shift + Tab Move the focus cursor to the previous item on the screen.
Enter
• Initiate an action.
• Select setting values.
• Open a menu.
• Accept a selection.
Up arrow Move the focus cursor to the previous item within a list.
Down arrow Move the focus cursor to the next item within a list.
Left arrow Move the focus cursor to the item on the left.
Right arrow Move the focus cursor to the item on the right.
Home
• Move the focus cursor to the first item on the list.
• Move the focus cursor to the beginning of an input field.
Esc
• Cancel a job.
• Go back to the previous page.
• Exit a pop-up screen of a setting without changing any value.
Page down
• Jump to the last item of a list within a single page.
• Move to the next page.
Page up
• Jump to the first item of a list within a single page.
• Move to the previous page.
F7 Mute the volume.
F6 Repeat the last spoken prompt.
Xerox
®
C315 Color Multifunction Printer, Xerox
®
C410 Color Printer, and Xerox
®
B410 Printer Accessibility Guide 17
Enabling User Selectable Accessibility Features

Xerox C410 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 4800 DPI
Duplex printing mode	Auto
Print resolution black	1200 x 1200 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.1 s
Time to first page (color, normal)	6.4 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (color, normal quality, A4/US Letter)	20 ppm
PCL fonts	89
Printer fonts	Bitmap, PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	China
Maximum duty cycle	125000 pages per month
Recommended duty cycle	0 - 10000 pages per month
Number of print cartridges	4
Page description languages	PCL 5, PCL 6, PDF 1.7, PostScript 3
Storage media	eMMC
Internal storage capacity	8 GB
Sound power level (printing)	67 dB
Sound pressure level (printing)	52 dB
Sound pressure level (quiet mode)	48 dB
Sound pressure level (duplex printing)	54 dB
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	FIPS 140-2, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11
Total input capacity	251 sheets
Total output capacity	125 sheets
Maximum input capacity	2001 sheets
Paper tray 1 input capacity	1 sheets
Custom media width	98 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight	60 - 200 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Multi-purpose tray media types	Bond paper, Envelopes, Glossy paper, Heavyweight paper, Labels, Letterhead, Plain paper
Maximum ISO A-series paper size	A4
AC input voltage	220 - 240 V
AC input frequency	47-63 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	22 W
Power consumption (printing)	530 W
Storage temperature (T-T)	-40 - 40 °C
Operating temperature (T-T)	15 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	595 mm
Package width	495 mm
Package height	402 mm
Package weight	23900 g
Cables included	AC
Included cartridge capacity (CMY)	2000 pages
Included cartridge capacity (black)	2400 pages
Display	LCD
Control type	Touch
Product color	Grey, White
Display diagonal	4.3 \
Market positioning	Home & office

Weight and Dimensions

Depth	423 mm
Width	445 mm
Height	318 mm
