Clearing Paper Jams 49
IE
IE
2. Open the top cover.
3. As necessary, hold the lever on the right side
of the fuser cover and open the fuser cover.
Important
• The fuser is hot. Do not touch areas with labels
indicating high temperature and those surrounding the
labels. Otherwise, you can get burnt.
4. While holding the cover open, use your other
hand to remove the jammed paper.
5. Close the top cover and then the front cover.
Important
• When closing the front cover, be careful not to get your
fingers caught between (the left, right, top, or bottom
edge of) the cover and the printer.
Paper Jams in the Duplex Unit
1. Open the bypass tray cover.
2. Open the upper cover.
3. Hold the handle on the center part of the
inner cover and open the inner cover.
4. Remove the jammed paper.
To Next Page
