Xerox PHASER 3435 Service Manual

General Procedures and Information
6-48 5/08 Phaser 3435
GP 10 Parts Life Cycle Maintenance Table
Print Cartridge
1. Print Cartridge Main Defects
- White Point, Black Point: White or Black point on printing image
- Image contamination: Dirty printing image
- Image Fainted: Entire Image is fainted and vertical white line emerge
- Black Line: Vertical black line emerge on printing image
2. Defect Symptoms
Supplies Life Cycle Condition
Engine
Condition
LCD
Indication
Customer
Panel
Manage
Responding
Print Car-
tridge
4K: For Prod-
uct
Toner Low Warning Ready Low
Toner
- 10% Remains
10K: For Sale Toner Empty Warning Ready Toner - Initialized at toner
change
Toner unin-
stalled
Fuser 80K(page):
Simplex
Exhausted No Indication No Indication Replaced at
Exhausted
Transfer
Roller
70K(page):
Simplex
Exhausted No Indication No Indication Replaced at
Exhausted
PickUP Roller 150K(page):
Simplex
Exhausted No Indication No Indication Replaced at
Exhausted
Symptoms Criterion Remarks
White, Black Point Clean Up OPC (10 times), if disappeared, no failure.
- If continuous, failure
System Setup ->
Maintenance-> Clean Drum
Image contamina-
tion (Toner leak-
age)
Dirty printing image or contaminated reverse side
- Clean up OPC (10 times) and inside of machine with cloth, if
disappeared, no failure.
Image Fainted After shake cartridge right and left 5~6 times, if printing image is
not fainted, no failure. (Toner Exhausted)
Vertical Black Line Vertical thin line emerge, if cartridge is scratched.
- (Customer fault)

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
