Xerox PHASER 3435 Service Manual

Status Indicator RAPs
2-4 5/08 Phaser 3435
RAP 2 Error Messages
Message Meaning Suggested solutions
Door Open The front cover or rear cover is not
securely latched.
Close the cover until it locks into place.
Duplex Jam 0 Check
Inside
Paper has jammed during duplex
printing.
Clear the jam.
Duplex Jam 1 Open/
Close Door
Paper has jammed during duplex
printing.
Clear the jam.
Fuser Door Open The fuser door is not securely
latched.
Open the rear cover and close the fuser door
until it locks into place. For the location of the
fuser door.
Install Toner A print cartridge is not installed. Install a print cartridge.
Invalid Toner The print cartridge you have installed
is not for your printer.
Install a genuine print cartridge, designed for
your printer.
Load Manual Press
Stop Key
The multi-purpose tray is empty in
manual feed mode.
Load a sheet of print material and press OK.
Low Heat Error Cycle
Power
There is a problem in the fuser unit. Replace to Fuser Unit.
LSU Hsync Error Cycle
Power
A problem has occurred in the LSU
(Laser Scanning Unit).
Replace to LSU Unit.
LSU Motor Error Cycle
Power
A problem has occurred in the LSU
(Laser Scanning Unit).
Replace to LSU Unit.
Main Motor Locked There is a problem in the main motor. Open and then close the front cover.
Open Heat Error Cycle
Power
There is a problem in the fuser unit. Unplug the power cord and plug it back in. If
the problem persists, please call for service.
Over Heat Error Cycle
Power
There is a problem in the fuser unit. Unplug the power cord and plug it back in. If
the problem persists, please call for service.
Paper Jam 0 Open/
Close Door
Paper has jammed in the feeding
area of the tray.
Clear the jam.
Paper Jam 1 Open/
Close Door
Paper has jammed in the fuser area. Clear the jam.
Paper Jam 2 Check
Inside
Paper has jammed in the paper exit
area.
Clear the jam.
Printing... The printer is printing jobs using the
displayed language.
Complete your printing.
Ready The printer is on-line and ready to
printer.
Use your printer.
Replace Toner This message appears between the
Toner Empty and Toner Low status.
Replace the print cartridge with a new one.

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
