Xerox PHASER 3435 User Manual

Basic Printing
17
Troubleshooting Tab
Click the Troubleshooting tab to access the following feature:
Printer Information Page
To print information pages or to perform diagnostic actions,
select an item from the list below and click
Print
Web Links
If you have an Internet connection and a browser installed,
click one of the web links to connect to a web page directly from
the driver.
About
Use the About tab to display the copyright notice and the
version number of the driver.
Printer Tab
If you access printer properties through the Printers folder, you
can view the
Printer tab. You can set the printer configuration.
The following procedure is for Windows XP. For other Windows OS,
refer to the corresponding Windows User's Guide or online help.
1 Click the Windows Start menu.
2 Select Printers and Faxes .
3 Select your printer driver icon.
4 Right-click on the printer driver icon and select
Properties .
5 Click the Printer tab and set the options.
1
2
3
1
2
3
Using a Favorite Setting
The Favorites option, which is visible on each properties tab,
allows you to save the current properties settings for future use.
To s ave a Favorites item:
1 Change the settings as needed on each tab.
2 Enter a name for the item in the Favorites input box.
3 Click Save .
When you save
Favorites , all current driver settings are
saved.
To use a saved setting, select the item from the
Favorites drop
down list. The printer is now set to print according to the
Favorites setting you selected.
To delete a Favorites item, select it from the list and click
Delete .
You can also restore the printer driver’s default settings by
selecting
Printer Default from the list.
Using Help
Your printer has a help screen that can be activated by clicking
the
Help button in the printer properties window. These help
screens give detailed information about the printer features
provided by the printer driver.
You can also click from the upper right corner of the window,
and then click on any setting.

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
