Xiaomi Mi Router AX1800 User Manual

Power on the router, then connect the Internet (WAN) port
to the DSL/Cable/satellite modem
* If your Internet network is connected via an Ethernet cable at the wall, connect
the Ethernet cable directly to the Internet (WAN) port on the router
Step 1: Connect the cables
English
3
DSL/Cable/
Satellite modem
WAN
LAN
or
Connect
the power
1 2
3
WAN
RESET

Xiaomi Mi Router AX1800 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1800 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	White
Housing material	Acrylonitrile butadiene styrene (ABS)
Antennas quantity	4
Flash memory	256 MB
Internal memory	128 MB
Processor manufacturer	Qualcomm
Output current	1 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK
Cables included	LAN (RJ-45)
Package type	Box

Weight and Dimensions

Depth	141 mm
Width	247 mm
Height	180 mm
