Xiaomi QiCycle EF1 User Manual

Schematic representation of accessories
Pedals х 2 Power
adaptor х1
Wrench (15мм)
х1
Hex key (5мм) х1
Quick start
Installation (assembly) of a steering tube
Install the steering tube in a vertical position. Make a tight
conjunction between steering pipes and a lower part of the bike.
Lift the latch to secure a position of a steering tube.
Adjusting a tilt of steering
Set a desired angle of a handlebar
and simultaneously tighten two screws
using a hex key (5 mm).
Adjusting a saddle height
Maximum safe height
Loosen a saddle clamp, and then select an
appropriate position and height of a saddle.
Tighten a clamp of saddle pin. Note that it
should not exceed maximum safe height.
Recommended saddle height:
stature

Xiaomi QiCycle EF1 Specifications

Power

continuous output power	180 W
rated output torque	7.3 Nm
maximum charging voltage	42 V
power input	36 V --- 6 A

Battery

battery capacity	5.8 Ah
battery type	18650 mAh lithium-ion battery
recharging time	3 hours
protection of the voltage	24.5 V

Performance

maximum speed	20 km/h
rated speed	about 260 r/min
duration of continuous use	45 km
payload	100 kg

Display and Connectivity

display size	1.8 inches
display resolution	160 x 128
type of wireless connectivity	Bluetooth 4.0

Weight and Dimensions

weight	14.5 kg
size	1290 x 540 x 910 mm
wheel size	16 inches
distance between front and rear wheels	870 mm
