Xiaomi QiCycle EF1 User Manual

Main parameters
Model: EF1;
Size: 1290 x 540 x 910mm;
Weight: 14.5kh;
Front fork: made from aluminum alloy;
Saddle pin: 33.9 x 580mm (produced from aluminum alloy)
Wheel size: 16 inches;
Method of braking, front brakes, rear brakes Shimano IM31;
Engine type: electric;
Rated speed: about 260 r / min;
Power input: 36V --- 6A;
Protection of the voltage: 24.5V;
Battery Type: 18650 mAh lithium-ion battery;
The duration of continuous use: 45 km;
Display: 1.8 inch, 160 x 128 TFT;
Type of wireless connectivity: Bluetooth 4.0;
Standard: Q / XMQJ001 - 2016;
A distance between front and rear wheels: 870 mm;
Payload: 100 kg
Frame: Aluminium crank 52T x 170mm;
Bushing: three-speed rear hub Shimano;
Stopping distance: on dry road no more than 4 m, in a wet - no more than
15m (speed bike 20 km / h);
Continuous output power: 180 W;
Rated output torque: 7.3 Nm;
Maximum speed: 20 km / h;
Overcurrent protection: 10;
Battery Capacity: 5.8 Ah / VTG 208.8;
Maximum charging voltage: 42 V;
Recharging time: 3 hours .;
CMIIT ID: 2016DP2241.
XIAOMI-MI.COM
The client company: Xiaomi Ecosystem company «Qiyi (Xiamen)
Technology»
Address: Xiamen, Huli District, Anling Street 97-99, 8 Floor, 01-07 Block

Xiaomi QiCycle EF1 Specifications

Power

continuous output power	180 W
rated output torque	7.3 Nm
maximum charging voltage	42 V
power input	36 V --- 6 A

Battery

battery capacity	5.8 Ah
battery type	18650 mAh lithium-ion battery
recharging time	3 hours
protection of the voltage	24.5 V

Performance

maximum speed	20 km/h
rated speed	about 260 r/min
duration of continuous use	45 km
payload	100 kg

Display and Connectivity

display size	1.8 inches
display resolution	160 x 128
type of wireless connectivity	Bluetooth 4.0

Weight and Dimensions

weight	14.5 kg
size	1290 x 540 x 910 mm
wheel size	16 inches
distance between front and rear wheels	870 mm
