Xilinx VCU118 Software Install And Board Setup

Optional Hardware Setup
Connect a 156.25 MHz clock
source to these SMA inputs:
– MGT226_CLK0, J30, J31 (Black)
– MGT233_CLK0, J32, J33 (Yellow)
– USER_CLK, J34, J35 (Red)
MGT226 and MGT233 require DC
Blocking Capacitors
– On all VCU118 boards through Rev 1.1
Use splitters if desired
Note: Presentation applies to the VCU118
