Chapter 1: Introduction
10 www.xilinx.com ZC702 and ZVIK Getting Started Guide
UG926 (v6.0) December 17, 2013
Zynq-7000 AP SoC Video and Imaging Kit Contents
The ZVIK contains all of the items included in the ZC702 evaluation kit plus the following
items. For more information on the HDMI input/output FMC module and ON Semiconductor
image sensor, refer to the Avnet product page [Ref 3].
HDMI input/output FPGA mezzanine card (FMC) module
ON Semiconductor VITA 2000 Color Image Sensor module
Standard interchangeable
2
/
3
-inch 8 mm C-mount lens
•Infrared (IR) cut filter
•Camera tripod
Lens holder
•Cables
°
Second HDMI cable
°
LCEDI image sensor cable
For reference design files, documents, and board source files, go to the Zynq-7000 AP
SoC Video and Imaging Kit documentation page.
Key Features of the ZVIK
Key features of the additional components of the Zynq-7000 AP SoC Video and Imaging kit
include:
•HDMI input/output FMC module
°
HDMI input
°
HDMI output
°
Video clock synthesizer
°
Interface for ON Semiconductor VITA image sensor module
ON Semiconductor VITA 2000 color image sensor module
°
Supports up to WXGA resolution: 1920 (H) x 1200 (V) format
°
92 frames per second (fps) at full resolution
°
4.8 μ m x 4.8 μ m pixel size
2
/
3
-inch optical format
°
Pipelined and triggered global shutter, rolling shutter
Send Feedback
