Xomax XM-2DTSB6219BT User Manual

CONTENTS
01
Panel Introduction
02
Remote control function
04
Other Functions
13
Disc Function Operation
06
Radio Function Operation
07
Entering the main interface
06
Turn on/off Host
06
Trouble shooting
14
External input operation
10
08
Multimedia function
BT Function Operation
09
10
Steering wheel setting(Optional)
11
Calendar setting
11
Setup
11
General setting
11
Language setting
12
Audio setting
12
Video setting
12
Touch calibration
12
Volume setting
Trouble Shooting
PROBLEM
CAUSE
SOLUTION
Cannot power on
Check whether power fuse
melt or not
Change fuse same as the old one
Some factors cause MPU
wrong operation
Press [RES] button on the panel by
penpoint, then, power on
After ignition switch
off, setting information
all lose
Change battery or fuse
Reset information and save
Poor performance of
radio station
Weak signal
Move the car to another place,then
research
Cannot load disc
There is a disc inside.
Eject disc,then,slot in new disc
Cannot play disc
Disc is scratched
Change new disc
Put wrong side of disc into the
unit
Slot in the disk with sign side up
Lens has dirty Clean lens by lens clean disc
Cannot switch
language/subtitle
There is only one language/
subtitle in disc
If disc is not with multi-language/
subtitle, it cannot switch language/
subtitle
No image
Other factors cause MPU
wrong operation
Press [RES] button on the panel by
penpoint, then ,power on
Cannot watch image
during driving
It's not allowed to watch
image during driving
Park the car in a safe place, Put
the car stall in “P” position, pull
up the hand brake
Wiring Diagram
This player is equipped with ISO standard connector, Please follow below instruction:
Red - ACC ON (+12V)
Yellow - 12V Constant
Black - Ground wire
Blue - Power Antenna / Remote Amp Tum On
Orange - Back-Up Camera Trigger (+)
Grey/Grey black - Right front speaker (+/-)
White/White black - Left front speaker (+/-)
Purple/Purple black - Right rear speaker (+/-)
Green/Green black - Left rear speaker (+/-)
Pink - Parking Brake (-)
Wiring Diagram
14
14

Xomax XM-2DTSB6219BT Specifications

General

Brand	Xomax
Model	XM-2DTSB6219BT
Category	Car Video System
Language	English
