9
2. REAR TRANSMISSION
930816
BB 8x16x5
980314
P 3x14
901404
SB M4x4
Apply oil from inside to prevent
breakage of the rubber boot.
Graphite Grease
(HUDY #106210)
NOTE
ORIENTATION
LONG CVD DRIVE SHAFT
Cut on both front and
rear bulkhead blocks
BEFORE inserting the clip on the central CVD shaft joint, apply a small amount of
threadlock on the area where the clip goes.
AFTER inserting the clip on the central CVD shaft joint, turn the clip so that the slot is
90°from the pin. This will prevent the pin from opening the clip.
Follow the TECH TIP on page 5
for drive shaft pin servicing.
DETAIL
DETAIL
BAG
➊
➊
➋
➋
➌
➌
➍
➍
352006 DIFF BULKHEAD BLOCK SET FRONT/REAR
353040 GRAPHITE REAR SHOCK TOWER - CNC MACHINED 3.5MM
355115 BEVEL DRIVE GEAR 13T
355236 CVD DRIVE SHAFT COUPLING - HUDY SPRING STEEL™
355416 CENTRAL CVD SHAFT UNIVERSAL JOINT - HUDY SPRING STEEL™
355640 REAR CENTRAL CVD DRIVE SHAFT - HUDY SPRING STEEL™
355471 DRIVE SHAFT LOCKING RING (2)
355472 DRIVE SHAFT BOOT (2)
➎
➎
355005
REAR DIFF
908312
Graphite Grease
(HUDY #106210)
REAR DIFF
50.000cSt
The ring can be assembled by hand,
but for easy disassembly we recommend
using snap ring pliers (HUDY #189040)
DETAIL
STEP DETAIL
➎
➎
Push joint against gear to remove gap.
Tighten setscrew onto gear flat spot.
908312
355471
355472
LONG
355640
355236
352006
355115
352006
353040
355416
980314
901404
930816
930816
PIN
STEP DETAIL
➍
step 1 step 2
step 3
OIL
901404 HEX SCREW SB M4x4 (10)
908312 HEX SCREW SOCKET HEAD CAP SCH M3x12 (10)
930816
BALL-BEARING 8x16x5 STEEL SEALED - GREASE (2)
980314 PIN 3x14 (10)
355005
DIFFERENTIAL 46T - V2 - SET
step 4
GTX8GTXE
Use HUDY Ball-Bearing
Grease or Oil for servicing:
#106220 - Standard
#106221 - Extra
#106222 - Premium
#106230 - Bearing Oil
908312
SCH M3x12
XRAY BALL-BEARING
#930816 8x16x5 GREASE STEEL INCLUDED
#930817 8x16x5 OIL STEEL OPTION
XRAY BALL-BEARING
#930816 8x16x5 GREASE STEEL INCLUDED
#930817 8x16x5 OIL STEEL OPTION
Ball-bearing with STEEL covers
Ball-bearing with STEEL covers
