6
TOP/BOTTOM VIEW
Top Bottom
Figure 1-5 Sample of VCI Box, screen 2
① DB15 Port: Used to connect the VCI box to the OBDII port on the
vehicle.
② USB-B Port: Used to connect the VCI box to the tablet using USB-B
to USB3.0 cable
①
②
