Page 71FT-2000D OPERATING MANUAL
ACTIVATING THE PARAMETRIC MICROPHONE EQUALIZER
ENHANCING TRANSMIT SIGNAL QUALITY
PARAMETRIC MICROPHONE EQUALIZER
(
SSB/AM/FM MODES
)
f3f2f1
+10dB
P
a
r
a
m
e
t
r
i
c
G
a
i
n
1. Adjust the
[
MIC
]
(gain) knob for SSB use, as described
on page 64.
2. Press the
[
PROC
]
button momentarily. The “ ”
icon will appear in the display, confirming that the
Parametric Microphone Equalizer is engaged.
ADVICE
A blinking “ ” icon indicates the Parametric
Microphone Equalizer menu settings have all been set
to “OFF” (“123 tAUd EQ1 FRQ,” “126 tAUd EQ2
FRQ,” “129 tAUd EQ3 FRQ”).
3. Press the PTT switch on the microphone, and speak
into the microphone in a normal voice level.
4. To switch the Parametric Microphone Equalizer off,
press the
[
PROC
]
button repeatedly until the “ ”
icon disappears.
[
PROC
]
Button
[
MIC
]
Knob
3-ST AGE PARAMETRIC EQUALIZER ADJUSTMENTS
(
SPEECH PROCESSOR: “OFF”
)
Center Frequency “123 tAUd EQ1-FREQ” “100”
(
Hz
)
~ “700”
(
Hz
)
“126 tAUd EQ2-FREQ” “700”
(
Hz
)
~ “1500”
(
Hz
)
“129 tAUd EQ3-FREQ” “1500”
(
Hz
)
~ “3200”
(
Hz
)
Parametric Gain “124 AUd EQ1-LVL”
(
Low
)
“–10”
(
dB
)
~ “+10”
(
dB
)
“127 tAUd EQ2-LVL”
(
Mid
)
“–10”
(
dB
)
~ “+10”
(
dB
)
“130 tAUd EQ3-LVL”
(
High
)
“–10”
(
dB
)
~ “+10”
(
dB
)
Q
(
Bandwidth
)
“125 tAUd EQ1-BW”
(
Low
)
“1” ~ “10”
“128 tAUd EQ2-BW”
(
Mid
)
“1” ~ “10”
“131 tAUd EQ3-BW”
(
High
)
“1” ~ “10”
3-ST AGE PARAMETRIC EQUALIZER ADJUSTMENTS
(
SPEECH PROCESSOR: “ON”
)
Center Frequency “132 tAUd PE1-FREQ” “100”
(
Hz
)
~ “700”
(
Hz
)
“135 tAUd PE2-FREQ” “700”
(
Hz
)
~ “1500”
(
Hz
)
“138 tAUd PE3-FREQ” “1500”
(
Hz
)
~ “3200”
(
Hz
)
Parametric Gain “133 tAUd PE1-LVL”
(
Low
)
“–10”
(
dB
)
~ “+10”
(
dB
)
“136 tAUd PE2-LVL”
(
Mid
)
“–10”
(
dB
)
~ “+10”
(
dB
)
“139 tAUd PE3-LVL”
(
High
)
“–10”
(
dB
)
~ “+10”
(
dB
)
Q
(
Bandwidth
)
“134 tAUd PE1-BW”
(
Low
)
“1” ~ “10”
“137 tAUd PE2-BW”
(
Mid
)
“1” ~ “10”
“140 tAUd PE3-BW”
(
High
)
“1” ~ “10”
