Legend for Figure 13
A. STANDARD, NON-SWIVEL SEAT B. FULL SUSPENSION SWIVEL SEAT
1. SEAT BELT
2.
WEIGHT ADJUSTMENT KNOB
3. RIDE POSITION INDICATOR
4. FORWARD/BACKWARD ADJUSTMENT LEVER
5. BACKREST ANGLE ADJUSTMENT LEVER
6. ARMREST
7. SWIVEL LATCH RELEASE LEVER
5. Do not drive a lift truck into an elevator unless authorized
to do so. Approach the elevator slowly. After the elevator is
properly leveled, the lift truck must be centered so that the
elevator is balanced.
When the lift truck is in the proper position in the elevator,
set the brakes, put the controls in NEUTRAL and shut off
the power. It is advisable that all other personnel leave the
elevator before the lift truck enters or leaves.
6. Drive carefully, observe traffic rules, and be in
full control of the lift truck at all times. Be com-
pletely familiar with all the driving and load handling
techniques contained in this Operating Manual.
Driving and Direction Changes
KNOW YOUR TRANSMISSION OPTION. Lift trucks cov-
ered in this manual built prior to January, 2011, can be
equipped with a Standard, Powershift 1 Speed, or Techtro-
nix 100 (1 speed) Transmission. Lift trucks covered in this
manual built after January, 2011 can be equipped with a
Powershift 1 Speed or Techtronix 100 (1 speed) Transmis-
sion. Read the following sections carefully. See Table 7
and Figure 14 for the features and operational differences
in these transmission types.
