Yamaha 01x User Manual

3
O1X
■ SPECIFICATIONS
■ General Specifications
Sampling Frequency Internal, External Normal rate: 44.1 kHz (-10 %) – 48 kHz (+6 %)
Double rate: 88.2 kHz (-10 %) – 96 kHz (+6 %)
Frequency Response 44.1 kHz, 48 kHz 20 Hz – 20 kHz 0 +1/-3dB, MIC/LINE IN to STEREO OUT (48 kHz)
88.2 kHz, 96 kHz 20 Hz – 40 kHz 0 +1/-3dB, MIC/LINE IN to STEREO OUT (96 kHz)
Total Harmonic Distortion Less than 0.02 % 1kHz, LINE IN to STEREO OUT
Dynamic Range 103 dB LINE IN to STEREO OUT
Noise level -105 dBV
Crosstalk 70 dB
DA converter 24 bit Linear, 128 times oversampling (44.1, 48 kHz)/64 times over sampling (88.2, 96 kHz)
AD converter 24 bit Linear, 128 times oversampling (44.1, 48 kHz)/64 times over sampling (88.2, 96 kHz)
Internal Signal Processing 32 bit (Accumulator 58 bit)
Interface Functions
mLAN Audio I/F 18 ch Input / 24 ch Output (44.1 kHz, 48 kHz),
10 ch Input / 16 ch Output (88.2 kHz, 96 kHz)
MIDI I/F 5 ports Input / 5 ports Output
(for DAW, MIDI-A, MIDI-B, Studio Manager and Program Change Control)
Mixer Functions 28 ch Digital Mixing (44.1, 48 kHz)/18 ch Digital Mixing (88.2, 96 kHz)
Input MIC/LINE Input 8 ch (with 1 channel switchable to HI-Z Input)
mLAN Input 16 ch (44.1 kHz, 48 kHz)/8ch (88.2 kHz, 96 kHz)
mLAN Monitor Input 2 ch (Stereo one system) is cascade-connected to the Monitor Out (Stereo Bus and Mix Balance
can be adjusted)
Stereo Input Stereo; two systems (combined use with Effect return) (44.1 kHz, 48 kHz)
Stereo one system (88.2 kHz, 96 kHz)
Digital Input Stereo; one system
Digital Cascade Input Stereo; one system is cascade-connected to the Stereo Bus (with attenuator)
Oscillator Sine (100 Hz, 1 kHz, 10 kHz) / Noise, 0 dB – -96 dB (1 dB step)
Can be output to Stereo Bus, Rec Bus, Aux 1 – 4
Output Stereo Bus 2 ch (Stereo one system)
Rec Bus 2 ch (Stereo one system)
Aux Bus 2 ch (Send 1, 2)
Effect Bus 2 ch (Sends 3, 4; combined use with Aux 3, 4)
Direct Output 24 ch (mLAN output from Input Module x 24) (44.1 kHz, 48 kHz) / 16 ch (88.2 kHz, 96 kHz)
Effector 2 units (43 preset types) (44.1 kHz, 48 kHz)/1 unit (88.2 kHz, 96 kHz)
Channel Module MIC/LINE Input 24 systems (A/D Input x 8 ch, mLAN Input x 16) (44.1 kHz, 48 kHz) / 16 systems (88.2 kHz, 96 kHz)
mLAN Input Attenuator, Phase, Insert, 4-Band EQ, Dynamics, Aux Send 1 – 4, Level, Pan
Stereo Input Two systems (44.1 kHz, 48 kHz)/One system (88.2 kHz, 96 kHz) Attenuator, Phase, 4-Band EQ,
Aux Send 1 – 4, Level, Pan
Output Module Stereo Output Attenuator, 4-Band EQ, Dynamics, Insert, Level, Pan balance
Rec Bus Output Dynamics, Insert, Level
Aux 1 – 4 Output Level
Number of memories Preset Area User Area
Scene Library 1 99
Channel Library 2 127
EQ Library 40 160
Dynamics Library 40 88
Effect 1/2 Library 43 85
Input Patch Library 1 32
Output Patch Library 1 32
