Yamaha ’09 YZF-R1 User Manual

– 18 –
11. Transmission Gear
Parts List
No. PART No. PART NAME Q'TY REMARKS
1 14B-17401-70-A MAIN AXLE ASSY. 1 AB
1 14B-17401-80-C MAIN AXLE ASSY. 1 C
* 2 14B-15163-00 HSG., BEARING 1
* 3 93306-20652 BRG. 1
4 14B-17121-70-A GEAR, 2ND PINION 1 A
4 14B-17121-80-B GEAR, 2ND PINION 1 BC
5 14B-17131-AA GEAR, 3RD PINION 1 AA
5 14B-17131-AB GEAR, 3RD PINION 1 AB
5 14B-17131-AC GEAR, 3RD PINION 1 AC
5 14B-17131-BB GEAR, 3RD PINION 1 BB
5 14B-17131-BA GEAR, 3RD PINION 1 BA
5 14B-17131-BC GEAR, 3RD PINION 1 BC
5 14B-17131-CC GEAR, 3RD PINION 1 CC
6 14B-17151-70-A GEAR, 5TH PINION 1 A
6 14B-17151-80-B GEAR, 5TH PINION 1 BC
7 14B-17161-70-A GEAR, 6TH PINION 1 A
7 14B-17161-80-B GEAR, 6TH PINION 1 B
7 14B-17161-90-C GEAR, 6TH PINION 1 C
8 14B-17402-70 DRIVE AXLE ASSY. 1
* 9 14B-17421-00 AXLE, DRIVE 1
* 10 93305-20605 BRG. 1
* 11 90387-30012 COLLAR 1
12 14B-17211-70-A GEAR, 1ST WHEEL 1 A
12 14B-17211-80-B GEAR, 1ST WHEEL 1 B
12 14B-17211-90-C GEAR, 1ST WHEEL 1 C
13 14B-17221-70-A GEAR, 2ND WHEEL 1 A
13 14B-17221-80-B GERA, 2ND WHEEL 1 B
13 14B-17221-90-C GERA, 2ND WHEEL 1 C
14 14B-17231-70-A GEAR, 3RD WHEEL 1 A
14 14B-17231-80-B GEAR, 3RD WHEEL 1 B
14 14B-17231-90-C GEAR, 3RD WHEEL 1 C
15 14B-17241-70-A GEAR, 4TH WHEEL 1 A
15 14B-17241-80-B GEAR, 4TH WHEEL 1 B
15 14B-17241-90-C GEAR, 4TH WHEEL 1 C
16 14B-17251-70-A GEAR, 5TH WHEEL 1 A
16 14B-17251-80-B GEAR, 5TH WHEEL 1 B
16 14B-17251-90-C GEAR, 5TH WHEEL 1 C

Yamaha ’09 YZF-R1 Specifications

General

Bore x Stroke	78.0mm x 52.2mm
Compression Ratio	12.7:1
Fuel Delivery	Fuel injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Final Drive	Chain
Front Suspension	43mm inverted fork; fully adjustable, 4.7-in travel
Rear Suspension	Single shock; fully adjustable, 4.7-in travel
Rear Brakes	220mm disc; single-piston caliper
Front Tire	120/70-ZR17
Rear Tire	190/55-ZR17
Wheelbase	55.7 in
Seat Height	32.8 in
Fuel Capacity	4.8 gal
Curb Weight	454 lb
Length	81.5 in
Width	28.1 in
Engine Type	998cc, liquid-cooled inline 4-cylinder DOHC; 16 valves
Transmission	6-speed, multiplate slipper clutch
Front Brakes	Dual 310mm discs; radial-mount forged 6-piston calipers
