Engine speed (rpm) 13900
Tire radius (mm) 311 perimeter (m) 1.954
Primary reduction ratio 43 65 1.512
• Values in the speed table may vary slightly according to tire manufacturer and size.
• Select after referring to the value in the speed table.
GEAR PLAN
The number
of teeth
Ratio
17 17 17 16 17 16 17 16 17 15 16 17 15 16 15 16 15 16 15 15 15
Engine
side
Secondary
reduction
ratio
(Sprocket)
P W 41 42 43 41 44 42 45 43 46 41 44 47 42 45 43 46 44 47 45 46 47
Wheel
side
1st
A 14 34 2.429 184.1 179.7 175.5 173.2 171.5 169.1 167.7 165.2 164.1 162.4 161.4 160.6 158.5 157.8 154.9 154.4 151.3 151.1 148.0 144.8 141.7
Speed
(km/h)
B 14 33 2.357 189.6 185.1 180.8 178.5 176.7 174.2 172.8 170.2 169.0 167.3 166.3 165.4 163.3 162.6 159.6 159.1 155.9 155.7 152.5 149.1 146.0
C 16 37 2.313 193.3 188.7 184.3 181.9 180.1 177.6 176.1 173.5 172.3 170.6 169.5 168.6 166.5 165.8 162.6 162.2 158.9 158.7 155.4 152.0 148.8
2nd
A 15 32 2.133 209.5 204.6 199.8 197.2 195.3 192.5 190.9 188.0 186.8 184.9 183.8 182.8 180.5 179.7 176.3 175.8 172.3 172.0 168.5 164.8 161.3
B 16 32 2.000 223.5 218.2 213.1 210.4 208.3 205.4 203.6 200.6 199.2 197.2 196.0 195.0 192.5 191.7 188.0 187.5 183.8 183.5 179.7 175.8 172.0
C 16 31 1.938 230.7 225.2 220.0 217.1 215.0 212.0 210.2 207.0 205.6 203.6 202.3 201.3 198.7 197.8 194.1 193.5 189.7 189.4 185.5 181.4 177.6
3rd
A 17 31 1.824 245.1 239.3 233.7 230.7 228.4 225.2 223.3 220.0 218.5 216.3 215.0 213.8 211.1 210.2 206.2 205.6 201.6 201.3 197.1 192.8 188.7
B 19 33 1.737 257.4 251.2 245.4 242.2 239.8 236.5 234.5 231.0 229.4 227.1 225.7 224.5 221.7 220.7 216.5 215.9 211.6 211.3 206.9 202.4 198.1
C 18 29 1.611 277.5 270.9 264.6 261.1 258.5 254.9 252.8 249.0 247.3 244.8 243.3 242.0 239.0 237.9 233.4 232.8 228.1 227.8 223.1 218.2 213.6
4th
A 20 32 1.600 279.4 272.7 266.4 263.0 260.3 256.7 254.6 250.7 249.0 246.5 245.0 243.7 240.6 239.6 235.1 234.4 229.7 229.4 224.6 219.7 215.0
B 23 35 1.522 293.8 286.8 280.1 276.5 273.7 269.9 267.6 263.6 261.8 259.2 257.6 256.3 253.0 251.9 247.1 246.4 241.5 241.2 236.2 231.0 226.1
C 21 31 1.476 302.8 295.6 288.7 285.0 282.2 278.2 275.9 271.8 269.9 267.2 265.6 264.2 260.8 259.7 254.8 254.0 249.0 248.6 243.4 238.2 233.1
5th
A 19 28 1.474 303.3 296.1 289.2 285.5 282.7 278.7 276.4 272.2 270.4 267.6 266.0 264.6 261.3 260.1 255.2 254.5 249.4 249.0 243.9 238.6 233.5
B 22 31 1.409 317.2 309.7 302.5 298.6 295.6 291.5 289.0 284.7 282.8 279.9 278.2 276.7 273.3 272.0 266.9 266.1 260.8 260.5 255.0 249.5 244.2
C 22 30 1.364 327.8 320.0 312.6 308.5 305.5 301.2 298.7 294.2 292.2 289.2 287.5 286.0 282.4 281.1 275.8 275.0 269.5 269.1 263.5 257.8 252.3
6th
A 21 28 1.333 335.3 327.3 319.7 315.5 312.4 308.0 305.5 300.9 298.8 295.8 294.0 292.5 288.8 287.5 282.1 281.2 275.7 275.3 269.5 263.7 258.1
B 25 33 1.320 338.7 330.6 322.9 318.7 315.6 311.1 308.5 303.9 301.8 298.8 297.0 295.4 291.7 290.4 284.9 284.1 278.4 278.0 272.2 266.3 260.7
C 26 33 1.269 352.2 343.8 335.8 331.5 328.2 323.6 320.9 316.1 313.9 310.8 308.9 307.2 303.4 302.0 296.3 295.4 289.6 289.2 283.1 277.0 271.1
