CON ROD
5VY-11654-01 BOLT,
CON-ROD
BIG END
M8 x 0.75 TURN OF NUT
METHOD:
RETIGHTEN TO
SNUG TORQUE
OF 19.6 (2.0) •
ANGLE OF 150 ±
5°.
8 APPLY “SUM-
ICO
MORI
ASSEMBLY
OIL
150”.
5VY-1165A-01
(Long bolt)
8
ACM rotor
90105-126A8 BOLT,
FLANGE
M12 x 1.25 70±5
(7.0±0.5)
1 FOR DETAILS,
SEE page 61.
SPROCKET,
CRANK
90105-10290 BOLT,
FLANGE
M10 x 1.25 60±5
(6.0±0.5)
1 APPLY OIL TO
SCREW
THREAD.
CAM CHAIN,
TENSIONER
91312-06025 BOLT,
HEXAGON
SOCKET
HEAD
M6 x 1.0 10±2
(1.0±0.2)
2
Install PIPE, 1
90110-05182 BOLT,
HEXAGON
SOCKET
HEAD
M6 x 1.0 10±2
(1.0±0.2)
1
Install PIPE, 2
90110-06256 BOLT,
HEXAGON
SOCKET
HEAD
M6 x 1.0 10±2
(1.0±0.2)
2
Install PIPE, 4
90110-06182 BOLT,
HEXAGON
SOCKET
HEAD
M6 x 1.0 10±2
(1.0±0.2)
1 WATER PUMP
SIDE
Install PIPE, 4
90110-06022 SCREW M6 x 1.0 10±2
(1.0±0.2)
1 RUBBER
MOUNT SIDE
Tighten HOSE
90450-38040 HOSE
CLAMP
ASSY
— REF. 1. 5 -2.5
(0.15 – 0.25)
3 BREAKAGE
OCCURS AT 4
-
5N•m.
90450-35001 3
Install PUMP
DRIVING
SPROCKET
90105-06066 BOLT,
FLANGE
M6 x 1.0 15±2
(1.5±0.2)
1DEGREASE
SCREW
THREAD.
Install PUMP
90110-06167 BOLT,
FLANGE
M6 x 1.0 12±2
(1.2±0.2)
2
THERMOSTAT
ASSY
90176-06014 CAP, NUT M6 x 1.0 10±2
(1.0±0.2)
2
Install PIPE, 5
90110-05182 BOLT,
HEXAGON
SOCKET
HEAD
M6 x 1.0 10±2
(1.0±0.2)
1
Install OIL
COOLER
5FL-12822-00 BOLT,
UNION
M20 x 1.5 63±3
(6.3±0.3)
1 APPLY OIL TO
SCREW
THREAD AND
BEARING
SURFACE
Engine
To be tightened Part No. Part Name Thread dia.
x
pitch
Tightening
torque N•m
(kgf•m)
Q’ty Remarks

Yamaha ’09 YZF-R1 Specifications

General

Bore x Stroke	78.0mm x 52.2mm
Compression Ratio	12.7:1
Fuel Delivery	Fuel injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Final Drive	Chain
Front Suspension	43mm inverted fork; fully adjustable, 4.7-in travel
Rear Suspension	Single shock; fully adjustable, 4.7-in travel
Rear Brakes	220mm disc; single-piston caliper
Front Tire	120/70-ZR17
Rear Tire	190/55-ZR17
Wheelbase	55.7 in
Seat Height	32.8 in
Fuel Capacity	4.8 gal
Curb Weight	454 lb
Length	81.5 in
Width	28.1 in
Engine Type	998cc, liquid-cooled inline 4-cylinder DOHC; 16 valves
Transmission	6-speed, multiplate slipper clutch
Front Brakes	Dual 310mm discs; radial-mount forged 6-piston calipers
