REMOTE CONTROL
Both the shifter and the throttle are actuated
by the remote control lever. Additionally, the
remote control also has the electrical
switches.
å Side mount remote control box
∫ Binnacle mount remote control box
ç Switch panel (for use with ∫)
1 Remote control lever
2 Neutral interlock trigger
3 Neutral throttle lever
4 Free accelerator
5 Main switch / choke switch
6 Engine stop lanyard switch
7 Power trim and tilt switch
8 Throttle friction adjusting screw
