PERIODIC MAINTENANCE AND MINOR REPAIR
6-10
6
Engine oil and oil filter element re-
placement
1. Warm up the engine for a few min-
utes.
2. Stop the engine. Place an oil pan
under the engine and remove the
oil filler cap.
3. Remove the drain bolt and drain
the oil.
4. Remove the cover and the oil filter
cover by removing the bolts.
5. Remove the oil filter and O-ring.
6. Reinstall the drain bolt and tighten
it to the specified torque.
7. Install a new oil filter and O-ring.
8. Install oil filter cover and cover,
then tighten the bolts.
9. Fill the engine with oil. Install the
oil filler cap and tighten it.
1. Engine oil filler cap 1. Cover
2. Bolt (× 3)
Tightening torque:
Drain bolt:
43 Nm (4.3 m·kg)
1. Bolt (× 5)
2. Oil filter cover
Recommended oil:
See page 8-1.
Oil quantity:
Total amount:
3.2 L
Periodic oil change:
2.6 L
With oil filter replacement:
2.8 L
