SPEC
2 - 17
MAINTENANCE SPECIFICATIONS
EC212300
ELECTRICAL
Item Standard Limit
Ignition system:
Advancer type Electrical ----
C.D.I.:
Magneto-model/manufacturer F5JG 10/YAMAHA ----
Source coil 1 resistance (color) 720 ~ 1,080 Ω at 20 ˚C (68 ˚F)
(Green – Brown)
----
Source coil 2 resistance (color) 44 ~ 66 Ω at 20 ˚C (68 ˚F)
(Black – Pink)
----
Pickup coil resistance (color) 248 ~ 372 Ω at 20 ˚C (68 ˚F)
(White – Red)
----
CDI unit-model/manufacturer 5JG-50/YAMAHA ----
Ignition coil:
Model/manufacturer 5BE-00/YAMAHA ----
Minimum spark gap 6 mm (0.24 in) ----
Primary winding resistance 0.20 ~ 0.30 Ω at 20 ˚C (68 ˚F) ----
Secondary winding resistance 9.5 ~ 14.3 kΩ at 20 ˚C (68 ˚F) ----
Part to be tightened Thread size Q’ty
Tightening torque
Nm m·kg ft·lb
Stator M6 × 1.0 3 10 1.0 7.2
Rotor M10 × 1.25 1 48 4.8 35
Ignition coil M6 × 1.0 2 7 0.7 5.1
