To install the rider seat
1. Insert the projection on the front of
the rider seat into the seat holder
as shown, and then place the seat
in the original position.
2. Install the passenger seat holder
by installing its bolts.
3. Install the passenger seat.
TIP
Make sure that the seats are properly
secured before riding.
EAU14192
Seats (XVS650AZ)
Passenger seat
To remove the passenger seat
Remove the nut and washer, and then
pull the passenger seat up.
To install the passenger seat
1. Insert the projections on the front
of the passenger seat into the
holders as shown and place the
seat in the original position.
2. Install the washer and nut, and
then tighten the nut to the specified
torque.
1. Bolt
2. Passenger seat holder
1. Seat holder
2. Projection
1. Nut
2. Washer
