OUTBOARD MOTOR DIMENSIONS
CLAMP BRACKET DIMENSIONS
Global model
F2A
F2.5A
US/CA model
F2.5A
Manual tilt
Symbol
mm (in.)
Symbol
mm (in.)
Symbol
mm (in.)
Symbol
mm (in.)
B1
—
B8
—
C1
22 (0.9)
D1
—
B2
—
B9
—
C2
58 (2.3)
D2
—
B3
—
B10
—
C3
—
D3
—
B4
—
B11
56 (2.2)
D4
—
B5
69 (2.7)
B12
40 (1.6)
B6
143.7 (5.7)
B7
—
B6
B12
B5
C/L
B5
B11
B11
C1
C2
37
39
