Yamaha CD-C600 Service Manual

9
CD-C600
CD-C600
■ INTERNAL VIEW
OPERATION (13) P.C.B. (R, L models)
OPERATION (10) P.C.B.
CM-230B UNIT
CLAMP ASS’Y
OPERATION (6) P.C.B.
MAIN P.C.B.
OPERATION (9) P.C.B.
OPERATION (14) P.C.B.
TRAY ASS’Y
OPERATION (5) P.C.B.
OPERATION (8) P.C.B.
OPERATION (7) P.C.B.
OPERATION (11) P.C.B.
OPERATION (12) P.C.B.
OPERATION (3) P.C.B.
OPERATION (2) P.C.B.
OPERATION (4) P.C.B.
OPERATION (1) P.C.B.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
12
11
1089
1
14
75
13
24
15 16 17 18
36

Yamaha CD-C600 Specifications

General

Frequency range	10 - 20000 Hz
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.003 %
CD-RW playback	Yes
File type	MP3, WMA
Device type	HiFi CD player
Product color	Black
Dimensions (WxDxH)	435 x 116 x 405 mm

Weight and Dimensions

Weight	6200 g
