Specifications
Sampling rate
MY8-AE, MY8-TD 39.69–50.88 kHz
MY8-AT 41.013–50.88 kHz
DA conversion resolution 24-bit linear, 128-times oversampling
Frequency response –3, +1 dB, 20 Hz–20 kHz
Dynamic Range
1
1. Measured with a 6 dB/octave filter at 12.7 kHz; equivalent to a 20 kHz filter with infinite
dB/octave attenuation.
110 dB (typical)
Gain Error ±1 dB @ 1 kHz
THD
2
2. 6 dB/octave filter @ 80 kHz.
* Where dB represents a specific voltage, 0 dB is referenced to 0.775 V rms, 0 dBV is refer-
enced to 1.00 V rms.
0.05%, 20 Hz–20 kHz
0.01% full scale output @ 1 kHz
Hum & Noise Level
1
–92 dBu (typical)
Crosstalk –70 dB between adjacent channels @ 1 kHz
Signal Delay 0.57 ms (digital input to analog output, fs = 48 kHz)
Indicators
PEAK 3 dB below full scale
NOMINAL 14 dB below full scale
SIGNAL 34 dB below full scale
LOCK Wordclock lock
POWER Power on/off
Power requirements
U.S.A. & Canada 120 V AC, 60 Hz
Europe 230 V AC, 50 Hz
Power consumption 40 W
Dimensions (W
×
H
×
D) 480 × 97.5 × 366.8 mm (18.9 x 3.84 x 14.44 inches)
Weight 7.5 kg (16.53 lbs)
Free-air operating temperature 10˚ C to 35˚ C (50˚ F to 95˚ F)
Storage temperature –20˚ C to 60˚ C (–4˚ F to 140˚ F)
Power cord length 1.9 m
Supplied Accessories Owner’s Manual
