Bus connections of n8/n12 and DAW
Cubase 5/Cubase 4/Cubase Studio 5/Cubase Studio 4/Cubase
Essential 5/Cubase Essential 4/Cubase AI 5/Cubase AI 4
By installing “n Extension” and using the templates, the input/output buses in Cubase are assigned to the device as
follows.
Cubase Output
n12 Input n12 Output
Cubase Input
Output Bus Device Port Device Port Input Bus
n12-L/R n12-5.1 n12 Monitor L → DAW TO ST-L 5.1(L)
CH1 Direct Out → n12 Direct Out 1 n12-Dir1
n12 Monitor R → DAW TO ST-R 5.1(R) CH2 Direct Out → n12 Direct Out 2 n12-Dir2
n12-9/10 n12 Monitor 9/C → Input Channel 9 5.1(C) CH3 Direct Out → n12 Direct Out 3 n12-Dir3
n12 Monitor 10/LFE → Input Channel 10 5.1(LFE) CH4 Direct Out → n12 Direct Out 4 n12-Dir4
n12-11/12 n12 Monitor 11/Ls → Input Channel 11 5.1(Ls) CH5 Direct Out → n12 Direct Out 5 n12-Dir5
n12 Monitor 12/Rs → Input Channel 12 5.1(Rs) CH6 Direct Out → n12 Direct Out 6 n12-Dir6
n12-1 n12 input 1 → Input Channel 1 CH7 Direct Out → n12 Direct Out 7 n12-Dir7
n12-2 n12 input 2 → Input Channel 2 CH8 Direct Out → n12 Direct Out 8 n12-Dir8
n12-3 n12 input 3 → Input Channel 3 CH9 Direct Out → n12 Direct Out 9 n12-Dir9/10
n12-4 n12 input 4 → Input Channel 4 CH10 Direct Out → n12 Direct Out 10
n12-5 n12 input 5 → Input Channel 5 CH11 Direct Out → n12 Direct Out 11 n12-Dir11/12
n12-6 n12 input 6 → Input Channel 6 CH12 Direct Out → n12 Direct Out 12
n12-7 n12 input 7 → Input Channel 7 REC BUS L → n12 REC Bus L n12-REC
n12-8 n12 input 8 → Input Channel 8 REC BUS R → n12 REC Bus R
n12-AUX n12 AUX L → DAW TO AUX-L STEREO BUS L → n12 ST Bus L n12-ST
n12 AUX R → DAW TO AUX-R STEREO BUS R → n12 ST Bus R
Cubase Output
n8 Input n8 Output
Cubase Input
Output Bus Device Port Device Port Input Bus
n8-L/R n8 Monitor L → DAW TO ST-L
CH1 Direct Out → n8 Direct Out 1 n8-Dir1
n8 Monitor R → DAW TO ST-R
CH2 Direct Out → n8 Direct Out 2 n8-Dir2
n8-5/6 n8 input 5 → Input Channel 5
CH3 Direct Out → n8 Direct Out 3 n8-Dir3
n8 input 6 → Input Channel 6
CH4 Direct Out → n8 Direct Out 4 n8-Dir4
n8-7/8 n8 input 7 → Input Channel 7
CH5 Direct Out → n8 Direct Out 5 n8-Dir5/6
n8 input 8 → Input Channel 8
CH6 Direct Out → n8 Direct Out 6
n8-1 n8 input 1 → Input Channel 1
CH7 Direct Out → n8 Direct Out 7 n8-Dir7/8
n8-2 n8 input 2 → Input Channel 2
CH8 Direct Out → n8 Direct Out 8
n8-3 n8 input 3 → Input Channel 3
REC BUS L → n8 REC Bus L n8-REC
n8-4 n8 input 4 → Input Channel 4
REC BUS R → n8 REC Bus R
n8-AUX n8 AUX L → DAW TO AUX-L
STEREO BUS L → n8 ST Bus L n8-ST
n8 AUX R → DAW TO AUX-R
STEREO BUS R → n8 ST Bus R
